Various Sizes Steel Lined PTFE Pipe Elbow Medium working temperature -50℃~180℃

DESCRIPTION

PTFE elbow

Purpose: Mainly used to connect two pipes with the same or different nominal diameters to make the pipes turn at a certain angle

Applicable medium: suitable for various concentrations of sulfuric acid, hydrochloric acid, hydrofluoric acid, aqua regia and various organic acids, strong acids, and strong oxygen Chemicals and other corrosive media

Nominal diameter: DN25-DN2000

Applicable temperature: ≤180℃ (different materials are used for different working conditions)

Applicable pressure: ≤3.0Mpa

Manufacturing process: molding process

The powder molding method lining process (isostatic pressing process) can also be made by winding process, but the shape of the pipe is diverse,Therefore, whether it is production efficiency or molding, it is now more processed by molding technology. Steel lined PTFE elbow can be processed 90° can also be processed into 45°, or according to the angle provided by the customer.

F4 powder molding method lining is a manufacturing process of equal volume, equal pressure and isothermal, which has gone through extruded tubes (loose lining, tight lining),PTFE tape winding, as well as the process evolution of PTFE winding with steel wire and steel mesh, so far F4 powder mold Pressure lining technology is the latest fifth-generation product of F4 lining, which can be used in higher positive and negative pressure, high temperature, and strong corrosion conditions.

It is used under the conditions of 200℃ and vacuum below 0.096MPa, and the operation of rapid cooling and rapid heating or alternating cooling and heating will not cause The polytetrafluoroethylene layer falls off, bulges and collapses, and expands and deforms, so as to integrate steel fluorine.

WORKING CHARACTERISTICS OF STEEL LINED PTFE PRODUCTS:

Performance: Medium working temperature: -50℃~180℃

Medium working pressure: positive pressure: 2.5MPa, negative pressure resistance 70KPa at room temperature

Corrosion resistance: steel PTFE composite pipe, in addition to molten metal lithium, potassium, sodium, chlorine trifluoride, three under high temperature

Except for oxygen fluoride and high-flow liquid fluorine, it can resist almost all chemical media.

Atmospheric aging resistance: radiation resistance and low permeability: long-term exposure to the atmosphere, the surface and performance remain unchanged.

Incombustibility: The oxygen limit index is below 90.

Acid and alkali resistance: insoluble in strong acids, strong alkalis and organic solvents.

Oxidation resistance: resistant to corrosion by strong oxidants.

WORKING PRINCIPLE:

With the strength and thickness of the steel as a strong backing, combined with the excellent corrosion resistance of PTFE, a flawless

The inner surface resists all corrodors and invaders. protects the steel and steel supports the PTFE.

Become the most loyal couple in the chemical industry equipment.

INFORMATION ABOUT OUR FACTORY

Our Service
1) Your inquiry will be replied within 2 hours during working time,Within 24hours when rest time.
2) Our working time is 7.30 AM --17:30 PM,Monday to Saturday.
3) General samples time can be arranged within 2--5days.
4) Orders will be produced exactly as request and approved samples.
5) When mass production,we send photos to show the production line.And confirm the estimate time again.
6) At the end of mass production,photos and samples will send to you for approval.You can arrange the inspection.
7) Before shipment,our QC will have inspection to make sure the quality.
8) We always try best to ensure every order to delivery in time.

Payment Terms
1) T/T,Cash,L/C.Weston Union
2) 30% deposit,70% balance before shipment.
3) Lead time: 15 days after received deposited for 2tons.
4) Delivery way: By sea,By air, By EMS,DHL,UPS,TNT,FedEx.

Zhenjiang Chunhuan Sealing Materials Co., Ltd (Group) is located in Yangzhong City, Jiangsu Province, China, Founded in 1985, after more than 30 years of continuous development, has become the production of fluorine plastic products scale backbone enterprises. Companies registered capital of 80.88 million yuan, with more than 8,000 yuan in fixed assets, 20,000 square meters of business premises, more than 200 workers.

Main products: PTFE molded tube, sheet, gasket, PTFE push, extrusion rod/ tube,PTFE skived sheet/film,PTFE filled products,Soft PTFE products,PTFE processing parts,Steel lining pipe fittings; Engineering plastics and Various metal seals, Metal sprial wound gasket; Fluorine rubber products, Gaskets, O-ring, oil seal etc.
