PTFE Known as the gold standard, PTFE material is often the first choice for many advanced applications such as aerospace, electronic, medical, chemical industry due to its superior lubricity, temperature and chemical resistance, biocompatibility and lowest coefficient of friction.
Properties
1, Low coefficient of friction;
2, Flexibility at low temperatures and thermal stability at high
temperatures,Broad working temperature range (500°F/260°C –
-292°F/-180°C);
3, Chemically resistant – all normal solvents, acids, and bases;
4, Low dielectric constant and low dissipation factor;
5, Non-flammability;
6, Non-stick, Easy to clean;
7, Long-term weathering;
8, High arc resistance, surface and volume resistivities
The Specification of PTFE Rod
| Dia(mm) | Length(mm) | Length(mm) |
| 1, 2, 3, 4 | continuous length | |
| 5, 6, 8, 10, 12, 15, 16, 18, 20, 22, 25, 28, 30, 32, 35, 40 | 1000 | 2000 |
| 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100 | 1000 | 2000 |
| 110, 120, 130, 140, 150, 160, 170, 180, 190, 200 | 1000 | 2000 |
| 210, 220, 230, 240, 250, 260, 270, 280, 300 | 300 | |
| 310, 320, 330, 340, 350, 360, 370, 380, 390, 400, 410, 420, 440, 450, 460, 470, 480, 490, 500 | 100 |
PTFE filled with other materials:
| Filled materials | Common filled ratio ( Quantity %) | Main performances |
| Bronze | 40, 60 | Increases hardness and wear resistance; Increases dimensional stability and compressive strength; Not suitable for corrosive or electrical applications |
| Carbon | 5, 10, 15 | Increases compressive strength, hardness, wear, and load
properties. Good chemical resistance;Improves electrical properties. |
| Graphite | 5, 10, 15 | Improves the deformation under load; Reduces initial wear; Improves thermal and eletrical conductivity |
| Glass Fiber | 10, 15, 25 | Increases compressive strength, rigidity and wear. Reduces creep and cold flow; Improve Dimensional Stability. |
| Carbon Fiber | 10 , 15, 25 | Increases compressive strength, hardness, wear, and load
properties. Reduces creep and cold flow |
| POB (polyphenyl ester) | 5, 10, 15 | Improve the lubrication performance;Enhance the mechanical strength; Increase using temperature |
| BaSO4 | 5, 10, 15 | Increases compressive strength, hardness and wear resistance Reduces creep |
| SiO2 | 5, 10, 15 | Increases hardness and wear resistance; Improve Dimensional Stability. |
| Glass beads | 5, 10, 15 | Reduces creep and cold flow;Lower density Increases hardness and wear resistance; |
| Others materials | PEEK(polyetheretherketone), PI(Polyimide), MoS2 are also ok | |
| Remarks | Some materials have similar enhancement effect, but degrees of enhancement are different. And they have different prices. More details please contact us. | |
