High Temperature Colored Durable Plastic Flexible Ptfe Thin Tube

Description

100% virgin PTFE tube are made by plunger extrusion of suspension polymerized PTFE resins. So that the fiber orientation, and after drying, high temperature sintering, shaping process and made of hose, usually packed in roll. PTFE tubing is manufactured by RAM extruding method with PTFE granular resin. PTFE is widely used as a pressure tubing in general chemical transfer applications such as delivery of natural gas and mineral oils, varnish or adhesive deliver lines. This tubing also serves numerous applications in the automation, electrical and appliance markets.

Specification

PTFE tubing

OD: 0.5-25mm T: 0.1-2.5mm Length Produced under requirements it is used to exectric insulated parts in high frequent conditions

Remark: we can fill all kinds of compound, for example: carbon, glass fiber, MOS2

Application

For transfer of high purity products, chemicals, dairy and cosmetic products. Also suitable for heat exchange and as protective sleeve for cables. They have excellent heat resistance, viscosity, chemical resistance, electrical insulation, etc.

Main properties

Features

1. Good heat resistance and weather resistance. Resin no load continuous use temperature -260℃~+260℃

2. For all chemicals, the solvent is inactive, and it is safer for a long time in strong acid, alkali, oxidant, oxide, aqua regia and other solutions; and it can withstand the concentration of 100% boiling hydrofluoric acid.

3. Good weather resistance, not easy to change after long- term use.

4. Non-sticky to all items

5. With flame resistance

6. Excellent electrical characteristics

Main applications: wires, cable sheaths, off-hose video tubes, acid-base tank heat exchange, corrosive fluid pipelines, etc.

Performance parameters

1. Withstand voltage: 150v-600v

• Working temperature: 80~260
• Melting point: 327 ℃
• Flame retardant: VW-1
• Breakdown strength: 26kv/mm
• Colors: can be customized as your requirement
• Related products through UL SGS certification, such as the best-selling products at home and abroad

Zhenjiang Chunhuan Sealing Materials Co., Ltd (Group) is located in Yangzhong City, Jiangsu Province, China, Founded in 1985, after more than 30 years of continuous development, has become the production of fluorine plastic products scale backbone enterprises. Companies registered capital of 80.88 million yuan, with more than 8,000 yuan in fixed assets, 20,000 square meters of business premises, more than 200 workers.

Main products: PTFE molded tube, sheet, gasket, PTFE push, extrusion rod/ tube,PTFE skived sheet/film,PTFE filled products,Soft PTFE products,PTFE processing parts,Steel lining pipe fittings; Engineering plastics and Various metal seals, Metal sprial wound gasket; Fluorine rubber products, Gaskets, O-ring, oil seal etc.
